| Art. No. | Profile type (mm) | Max useful stroke (mm) | Forward speed (m/s) | Nominal screw Ø (mm) | Nr. of runners |
|---|---|---|---|---|---|
| ML30HPV screw d8xp2 | 30x35 | 400 | 100 | 8x2 | 2 |
| ML30HPV screw d8xp8 | 30x35 | 400 | 150 | 8x8 | 2 |
| ML45HPV screw d10xp3 | 45x48 | 600 | 150 | 10x3 | 1 |
| ML45HPV screw d10xp10 | 45x48 | 600 | 400 | 10x10 | 1 |
| ML60HPV screw d16xp5 | 60x60 | 1500 | 250 | 16x5 | 2 |
| ML60HPV screw d16xp10 | 60x60 | 1500 | 500 | 16x10 | 2 |
| ML80HPV screw d20xp5 | 80x82 | 2000 | 250 | 20x5 | 2 |
| ML80HPV screw d20xp20 | 80x82 | 2000 | 1000 | 20x20 | 2 |
| ML1200HPV screw d25xp5 | 120x90 | 2500 | 250 | 25x5 | 2 |
| ML1200HPV screw d25xp10 | 120x90 | 2500 | 500 | 25x10 | 2 |
| ML1200HPV screw d25xp25 | 120x90 | 2500 | 1250 | 25x25 | 2 |
d=screw nominal diameter p=screw pitch
| ML30HPV screw d8xp2 | Drive with balls recirculating screw, belt 30mm, screw d8xp2 | ML30HPV vite d8xp2 | 0.00€ | |
| ML30HPV screw d8xp8 | Drive with balls recirculating screw, belt 30mm, screw d8xp8 | ML30HPV vite d8xp8 | 0.00€ | |
| ML45HPV screw d10xp3 | Drive with balls recirculating screw, belt 45mm, screw d10xp3 | ML45HPV vite d10xp3 | 0.00€ | |
| ML45HPV screw d10xp10 | Drive with balls recirculating screw, belt 45mm, screw d10xp10 | ML45HPV vite d10xp10 | 0.00€ | |
| ML60HPV screw d16xp5 | Drive with balls recirculating screw, belt 60mm, screw d16xp5 | ML60HPV vite d16xp5 | 0.00€ | |
| ML60HPV screw d16xp10 | Drive with balls recirculating screw, belt 60mm, screw d16xp10 | ML60HPV vite d16xp10 | 0.00€ | |
| ML80HPV screw d20xp5 | Drive with balls recirculating screw, belt 80mm, screw d20xp5 | ML80HPV vite d20xp5 | 0.00€ | |
| ML80HPV screw d20xp20 | Drive with balls recirculating screw, belt 80mm, screw d20xp20 | ML80HPV vite d20xp20 | 0.00€ | |
| ML120HPV screw d25xp5 | Drive with balls recirculating screw, belt 120mm, screw d25xp5 | ML120HPV vite d25xp5 | 0.00€ | |
| ML120HPV screw d25xp10 | Drive with balls recirculating screw, belt 120mm, screw d25xp10 | ML120HPV vite d25xp10 | 0.00€ | |
| ML120HPV screw d25xp25 | Drive with balls recirculating screw, belt 120mm, screw d25xp25 | ML120HPV vite d25xp25 | 0.00€ |
