| Art. No. | Material | Ø (mm) | Thickness (mm) | Min. L (mm) | Max L (mm) | Assembly set |
|---|---|---|---|---|---|---|
| 905100-L | aluminium | external 50, internal 47 | 1,5 | 118 | 800 | with nr.2 lateral pins 700251P, through pin 700251P-L and support 700412 |
| 905101-L | zinc plated iron | external 50, internal 47 | 1,5 | 118 | 800 | with nr.2 lateral pins 700251P, through pin 700251P-L and support 700412 |
| 905102-L | stainless steel | external 50, internal 47 | 1,5 | 118 | 800 | with nr.2 lateral pins 700251P, through pin 700251P-L and support 700412 |
| 905103-L | PVC | external 52, internal 47 | 2,5 | 118 | 300 | with nr.2 lateral pins 700251P, through pin 700251P-L and support 700412 |
Contact our Technical Department for special requirements regarding thickness, length or load capacity.
| 905100-L | Aluminium motorized roller with caps 700253-700252 | 905100-L | 0.00€ | |
| 905101-L | Zinc plated iron motorized roller with caps 700253-700252 | 905101-L | 0.00€ | |
| 905102-L | Stainless steel motorized roller with caps 700253-700252 | 905102-L | 0.00€ | |
| 905103-L | PVC motorized roller with caps 700253-700252 | 905103-L | 0.00€ |
